Артикул: TO25-Z10
В наличии
GIGABYTE TO25-Z10 (rev. AA01)
Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.
Подберем решение под ваши задачи
Поможем выбрать подходящий вариант, проверим совместимость и подготовим коммерческое предложение
Не отвечаем 5 минут — скидка на весь заказ!
Нужна скидка? Звони — сделаем лучшее предложение
Работаем по всей России
Возможны самовывоз и доставка по всей территории России
Надежность
Профессиональная поддержка
Описание товара GIGABYTE TO25-Z10 (rev. AA01)
ORv3 Compute Node - AMD EPYC™ 9004 - 2OU 2-Node UP 4-Bay E1.S Gen4 NVMe
- Single AMD EPYC™ 9004 Series Processors (with AMD 3D V-Cache™ Technology)
- 12-Channel RDIMM DDR5, 12 x DIMMs
- Dual ROM Architecture
- 4 x E1.S Gen4 NVMe hot-swappable bays
- 1 x M.2 slot with PCIe Gen4 x4 interface (optional)
- 2 x LP PCIe Gen5 x16 slots
- 1 x OCP 3.0 Gen5 x16 slot
- 48V DC Bus Bar power solution
Технические характеристики
Dimensions (WxHxD, mm)
2OU 2-Node
262.7 x 90 x 740
262.7 x 90 x 740
Open Rack Version
ORv3
Motherboard
MZ13-HD0
CPU
AMD EPYC™ 9004 Series Processors
AMD EPYC™ 9004 Series Processors with AMD 3D V-Cache™ Technology
Single processor, 5nm technology
*Up to 128 cores, 256 threads
cTDP up to 300W at ambient 35°C
*cTDP supported up to 400W under limited thermal conditions. Please contact technical support for more details.
AMD EPYC™ 9004 Series Processors with AMD 3D V-Cache™ Technology
Single processor, 5nm technology
*Up to 128 cores, 256 threads
cTDP up to 300W at ambient 35°C
*cTDP supported up to 400W under limited thermal conditions. Please contact technical support for more details.
Memory
12 x DIMM slots
DDR5 memory supported only
12-Channel memory architecture
RDIMM up to 96GB supported
3DS RDIMM up to 256GB supported
Memory speed: Up to 4800 MT/s
DDR5 memory supported only
12-Channel memory architecture
RDIMM up to 96GB supported
3DS RDIMM up to 256GB supported
Memory speed: Up to 4800 MT/s
LAN
Front side:
1 x 10/100/1000 Mbps Management LAN
1 x 10/100/1000 Mbps Management LAN
Storage
Front side:
4 x 9.5mm E1.S Gen4 NVMe hot-swappable bays
4 x 9.5mm E1.S Gen4 NVMe hot-swappable bays
SAS
N/A
RAID
N/A
Expansion Slots
Riser Card CRSH01Q:
- 1 x PCIe x16 (Gen5 x16) low-profile slot
Riser Card CRSH01R:
- 1 x PCIe x16 (Gen5 x16) low-profile slot
1 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth
Supports NCSI function
Optional 1 x M.2 slot (CMTP192):
- M-key
- PCIe Gen4 x4
- Supports 2280/22110 cards
- 1 x PCIe x16 (Gen5 x16) low-profile slot
Riser Card CRSH01R:
- 1 x PCIe x16 (Gen5 x16) low-profile slot
1 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth
Supports NCSI function
Optional 1 x M.2 slot (CMTP192):
- M-key
- PCIe Gen4 x4
- Supports 2280/22110 cards
Front I/O
2 x USB 3.2 Gen1
1 x VGA
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x System status LED
1 x ID LED
1 x VGA
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x System status LED
1 x ID LED
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
- Optional TPM2.0 kit: CTM010
Power Supply
Supports up to 1600W
System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Please refer to OS compatibility table in support page
System Fans
N/A
Packaging Dimensions
N/A
Packaging Content
1 x TO25-Z10-AA01
1 x CPU heatsink
1 x CPU heatsink
Part Numbers
- Barebone package: 6NTO25Z10DR000AA01*
- Motherboard: 9MZ13HD0UR-000
- CPU heatsink: 25ST1-143100-A0R
- Front panel board - COFP111: 9COFP111NR-00
- Riser card - CRSH01Q: 9CRSH01QNR-00
- Riser card - CRSH01R: 9CRSH01RNR-00
- EDSFF base board - COBP740: 9COBP740NR-00
- EDSFF riser card - CSPP010: 9CSPP010NR-00
Optional parts:
- M.2 expansion card - CMTP192: 9CMTP192NR-00
- Motherboard: 9MZ13HD0UR-000
- CPU heatsink: 25ST1-143100-A0R
- Front panel board - COFP111: 9COFP111NR-00
- Riser card - CRSH01Q: 9CRSH01QNR-00
- Riser card - CRSH01R: 9CRSH01RNR-00
- EDSFF base board - COBP740: 9COBP740NR-00
- EDSFF riser card - CSPP010: 9CSPP010NR-00
Optional parts:
- M.2 expansion card - CMTP192: 9CMTP192NR-00
No. of Bus Bars
1 x 48V Bus Bar
