Описание товара GIGABYTE E152-ZE0 (rev. A00)
Edge Server - AMD EPYC™ 7003 - 1U UP 2 x PCIe Gen4 GPUs
- NVIDIA-Certified Systems™ - Data Center Servers
- NVIDIA-Certified Systems™ - High-Density VDI Servers
- NVIDIA-Certified Systems™ - Edge Systems
- Supports 1 x Dual slot or 2 x Single slot GPUs
- AMD EPYC™ 7003 Series processors
- Single processor, 7nm technology
- 8-Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
- 2 x 1Gb/s LAN ports via Intel® I350-AM2
- 1 x Dedicated management port
- 2 x 2.5" Gen4 NVMe/SATA hot-swappable bays
- 2 x M.2 slots with PCIe Gen4 x4 interface
- 2 x FHFL PCIe Gen4 x16 slots for GPUs
- 2 x LP PCIe Gen4 x16 slots
- 1 x OCP 3.0 Gen4 x16 slot
- Single 800W 80 PLUS Platinum power supply (-A00)
- Single 800W 80 PLUS Titanium power supply (-AT0)
Технические характеристики
Dimensions (WxHxD, mm)
1U
438 x 43.5 x 400
438 x 43.5 x 400
Motherboard
MZE2-G10
CPU
AMD EPYC™ 7003 Series processors
Single processor, 7nm technology
Up to 64 cores, 128 threads
cTDP up to 280W
Compatible with AMD EPYC™ 7002 Series processors
Single processor, 7nm technology
Up to 64 cores, 128 threads
cTDP up to 280W
Compatible with AMD EPYC™ 7002 Series processors
Socket
1 x LGA 4094
Socket SP3
Socket SP3
Chipset
System on Chip
Memory
8 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
Memory speed: Up to 3200/2933 MT/s
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
Memory speed: Up to 3200/2933 MT/s
LAN
Front side:
2 x 1Gb/s LAN ports (Intel® I350-AM2)
Support NCSI function
1 x 10/100/1000 Mbps Management LAN
2 x 1Gb/s LAN ports (Intel® I350-AM2)
Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Storage
Front side:
2 x 2.5" Gen4 NVMe/SATA hot-swappable bays
2 x 2.5" Gen4 NVMe/SATA hot-swappable bays
SAS
N/A
RAID
N/A
Expansion Slots
1 x PCIe x16 (Gen4 x16) FHFL slot, for GPUs
1 x PCIe x16 (Gen4 x16) FHFL slot, for GPUs, occupied when Dual slot GPU is inserted
2 x PCIe x16 (Gen4 x16) low-profile slots
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth
Supports NCSI function
2 x M.2 slots (CMTP182):
- M-key
- PCIe Gen4 x4
- Supports 2280/22110 cards
1 x PCIe x16 (Gen4 x16) FHFL slot, for GPUs, occupied when Dual slot GPU is inserted
2 x PCIe x16 (Gen4 x16) low-profile slots
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth
Supports NCSI function
2 x M.2 slots (CMTP182):
- M-key
- PCIe Gen4 x4
- Supports 2280/22110 cards
Internal I/O
1 x TPM header
1 x USB 3.0 connector
1 x Front Panel connector
1 x Backplane board connector
1 x USB 3.0 connector
1 x Front Panel connector
1 x Backplane board connector
Front I/O
2 x USB 3.0
1 x Mini-DP
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x System status LED
1 x Mini-DP
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x System status LED
Rear I/O
N/A
Backplane Board
Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s
PCIe Gen4 x4 or SATA 6Gb/s
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
Single 800W 80 PLUS Platinum power supply (-A00)
AC Input:
- 100-240V~/ 10-4A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 4.5A
DC Output:
- Max 800W
+12V/ 66A
+12Vsb/ 2.5A
Single 800W 80 PLUS Titanium power supply (-AT0)
AC Input:
- 100-127V ~/ 10A, 50-60Hz
- 200-240V~/ 5A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 5A
DC Output:
- Max 800W
+12.2V/ 65A
+12.2Vsb/ 3A
Note:
1. If using 280W CPU, please select 1300W power supply.
2. If using >250W Dual slot GPU or 2 x Single slot >125W GPUs, please select 1300W power supply.
AC Input:
- 100-240V~/ 10-4A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 4.5A
DC Output:
- Max 800W
+12V/ 66A
+12Vsb/ 2.5A
Single 800W 80 PLUS Titanium power supply (-AT0)
AC Input:
- 100-127V ~/ 10A, 50-60Hz
- 200-240V~/ 5A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 5A
DC Output:
- Max 800W
+12.2V/ 65A
+12.2Vsb/ 3A
Note:
1. If using 280W CPU, please select 1300W power supply.
2. If using >250W Dual slot GPU or 2 x Single slot >125W GPUs, please select 1300W power supply.
System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP/AD/RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Citrix Hypervisor 8.2.0 or later
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Citrix Hypervisor 8.2.0 or later
System Fans
2 x 40x40x28mm (25,000rpm)
5 x 40x40x56mm (25,000rpm)
5 x 40x40x56mm (25,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 7.2 kg
Gross Weight: 11.12 kg
Gross Weight: 11.12 kg
Packaging Dimensions
628 x 549 x 200 mm
Packaging Content
1 x E152-ZE0
1 x CPU heatsink
*Rail kit not included. Please refer to optional parts for compatible rail kit.
1 x CPU heatsink
*Rail kit not included. Please refer to optional parts for compatible rail kit.
Part Numbers
- Barebone package: 6NE152ZE0MR-00-A*
- Motherboard: 9MZE2G10NR-00
- CPU heatsink: 25ST1-453211-A3R
- Backplane board - CBPE020: 9CBPE020NR-00
- Fan module (40x40x28mm): 25ST2-442827-D0R
- Fan module (40x40x56mm): 25ST2-44562M-D0R
- Fan module (40x40x56mm): 25ST2-44562N-D0R
- M.2 riser card - CMTP182: 9CMTP182NR-00
- Riser card - CRSE020: 9CRSE020NR-00
- Riser card - CRSH01E: 9CRSH01ENR-00
- Riser card - CRSH01H: 9CRSH01HNR-00
- Power supply (-A00): 25EP0-208004-L0S
- Power supply (-AT0): 25EP0-20800C-G1S
Optional parts:
- 2-Section Rail kit (385-480mm): 25HB2-3A0204-K0R
- 2-Section Rail kit (660-840mm): 25HB2-3A0203-K0R
- GPU power cable (CPU 8pin, 250mm): 25CRI-250103-Y4R
- GPU power cable (PCIe 8pin, 220mm): 25CRI-220306-Y4R
- Motherboard: 9MZE2G10NR-00
- CPU heatsink: 25ST1-453211-A3R
- Backplane board - CBPE020: 9CBPE020NR-00
- Fan module (40x40x28mm): 25ST2-442827-D0R
- Fan module (40x40x56mm): 25ST2-44562M-D0R
- Fan module (40x40x56mm): 25ST2-44562N-D0R
- M.2 riser card - CMTP182: 9CMTP182NR-00
- Riser card - CRSE020: 9CRSE020NR-00
- Riser card - CRSH01E: 9CRSH01ENR-00
- Riser card - CRSH01H: 9CRSH01HNR-00
- Power supply (-A00): 25EP0-208004-L0S
- Power supply (-AT0): 25EP0-20800C-G1S
Optional parts:
- 2-Section Rail kit (385-480mm): 25HB2-3A0204-K0R
- 2-Section Rail kit (660-840mm): 25HB2-3A0203-K0R
- GPU power cable (CPU 8pin, 250mm): 25CRI-250103-Y4R
- GPU power cable (PCIe 8pin, 220mm): 25CRI-220306-Y4R
